Revised Cut-Off Grade Results In Significant Expansion Of Avalon Rare Metals (TSE:AVL) Nechalacho REE Deposit Resource Estimate
Toronto, June 15, 2010 AEST (ABN Newswire) - Avalon Rare Metals Inc. (
TSE:AVL) (OTCQX:AVARF) is pleased to announce the results of a revised 43-101-compliant resource estimate for the Nechalacho Rare Earth Element ("REE") deposit, Thor Lake, Northwest Territories, Canada. The revised resource estimate was prepared by independent consultant Scott Wilson Roscoe Postle Associates Inc. ("Scott Wilson RPA"), as part of the Prefeasibility Study ("PFS"), that it is preparing for the Company. The PFS is nearing completion and the results of the economic analysis will be disclosed within the next two weeks.
New estimates on operating costs and revenues resulted in the determination of a lower economic cut-off grade which, along with the re-classification of some Inferred Resources as Indicated, resulted in a significant expansion of the total Indicated and Inferred Resources in the deposit. Additions to the Indicated Resources in the high-grade Basal Zone significantly benefited the mine development plan and consequently, contributed to the delay in finalizing the economic model for the PFS.
Inferred Mineral Resources for both Basal and Upper Zones now total 175.93 million tonnes averaging 1.43% TREO, representing 2.5 million tonnes of contained TREO(1). This amounts to a 100% increase in contained TREO from the previously reported estimate (January 14, 2010). With this new total resource estimate, Nechalacho now ranks as the second largest REE deposit in the world by reported TREO and the third largest contained niobium deposit in the world by reported Nb2O5.
Commented Avalon CEO, Don Bubar, "The magnitude of this expansion of the 43-101 compliant resources in the Nechalacho deposit certainly came as a pleasant surprise. What is perhaps even more remarkable is that this revised resource estimate does not include the results from the 2010 winter drilling program where 11,398 metres of drilling was completed in 43 holes. Given the initial assay results that were reported on May 12, 2010, we can almost certainly anticipate a further expansion of the Nechalacho deposit resources when the next resource estimate update is completed later this summer."
The 43-101 compliant resources as currently established by Scott Wilson RPA, from all the drilling completed up to the end of 2009, are summarised in the table below. Assays for each of the individual rare earth elements will be posted on the Thor Lake Introduction page under Reports and Tables (http://www.avalonraremetals.com/projects/thor_lake/thor_lake_intro/).
------------------------------------------------------ Tonnes % % % % ppm ppm (millions) TREO HREO ZrO2 Nb2O5 Ga2O3 Ta2O5------------------------------------------------------Basal Zone------------------------------------------------------Indicated 14.48 1.82 0.40 3.38 0.437 144 430Inferred 76.87 1.60 0.33 3.14 0.443 134 413------------------------------------------------------Upper Zone------------------------------------------------------Indicated 6.89 1.45 0.17 1.86 0.286 175 194Inferred 99.06 1.29 0.12 2.44 0.364 172 210------------------------------------------------------TotalInferred 175.93 1.43 0.21 2.74 0.399 155 298------------------------------------------------------
Notes:
1. CIM definitions were followed for Mineral Resources.
2. Mineral Resources estimates are based on the following price assumptions: US$21.94/kg TREO (based on the typical distribution of the individual REE in the Basal Zone), US$3.76/kg zirconium oxide, US$130/kg tantalum oxide and US$45/kg niobium oxide.
3. An exchange rate of CND$1.11/USD$1.00 was used.
4. Mineral Resources are estimated using a Net Metal Return ("NMR") cut-off value
of CND$260/tonnes.
5. A minimum mining width of five metres was used.
6. Resource densities in the block model are interpolated values averaging 2.87 t/m3. Density is estimated from 7,622 density measurements on drill core completed by Avalon.
7. Indicated Mineral Resources are inclusive of Mineral Reserves.
8. Totals may differ from sum or weighted sum of numbers due to rounding.
9. The resources are estimated based on assays of 155 drill holes drilled by Avalon through the end of 2009 plus re-assay by Avalon of core from 6 historic drill holes. Drill results from the winter 2010 program are not included.
10. The sampling protocols as applied by Avalon were reported in detail in News
Release 10-06, May 12, 2010, available on Avalon?s website.
Global REE Deposits Ranking
A review of REE deposit resources documented from around the world by IMCOA, a consultancy from Australia led by Dudley Kingsnorth ("Kingsnorth"), has ranked the largest REE deposits globally outside of China. (See American Society of Mining Engineers (SME) meeting in March, 2010, available at):
http://www.smenet.org/rareEarthsProject/SME_2010_Kingsnorth.pdf
Using the criteria defined by Kingsnorth, the HREO rich Nechalacho deposit now ranks as the second largest REE deposit in the world, after the giant light REE deposits of Bayan Obo in China, yet the full extent of the Nechalacho deposit is still undefined. Kingsnorth documents only four deposits globally with greater than 1 million tonnes contained TREO.
In addition, the Nechalacho deposit (especially the Basal Zone) has the highest proportion of the more valuable HREO and consequently yields a higher value per tonne.
-----------------------------------------------------------------Deposit Contained tonnes % HREO Contained tonnes TREO HREO-----------------------------------------------------------------Bayan Obo, China 56,900,000 2% 1,138,000-----------------------------------------------------------------Nechalacho Inferred,Canada 2,500,000 22% 550,000-----------------------------------------------------------------Kvanefeld, Greenland 2,150,000 14% 301,000-----------------------------------------------------------------Mountain Pass, USA 1,840,000 0.98% 18,032-----------------------------------------------------------------
The Nechalacho deposit is also a very significant resource of niobium (Nb), tantalum (Ta) and zirconium (Zr). For contained Nb2O5 (niobium pentoxide) it ranks as the third largest deposit in the world:
-------------------------------------------------------------------Deposit Millions % Nb2O5 Contained Source tonnes tonnes Nb2O5-------------------------------------------------------------------Araxa, Brazil 440 2.75 12,100,000 CBMM website, reserves-------------------------------------------------------------------Bayan Obo, China 769 0.13 999,700 USGS-------------------------------------------------------------------Nechalacho Inferred,Canada 175.93 0.40 701,081 This release-------------------------------------------------------------------Mount Weld, Australia 37.7 1.07 403,390 Lynas website-------------------------------------------------------------------Catalao, Brazil 25.6 1.23 314,880 Anglo American website-------------------------------------------------------------------Niobec, Canada 37.912 0.58 219,890 IAMGOLD website-------------------------------------------------------------------
Methodology
The current resource estimate for the Nechalacho deposit is based upon detailed core logging, assays and geological interpretation by Avalon's consulting geologists. In total, 206 drill holes were used for the estimate of which 51 are historic and 155 are Avalon diamond drill holes (drilled and sampled from 2007 to 2009). Complete REE analyses are available for six historic holes and all 155 Avalon holes. These holes and their related assays formed the basis for creating two domains of REE mineralization: an upper light rare earth element-enriched domain (Upper Zone) and a lower heavy rare earth element-enriched domain (Basal Zone).
The previous resource estimate (January 14, 2010) used a 1.60% TREO cut-off grade. This was based upon the estimated TREO revenues and operating costs determined initially by the QP at the time, but it did not incorporate potential by-product revenue streams from other rare metals now demonstrated to be recoverable and saleable such as zirconium, niobium and tantalum. This resulted in an Indicated Mineral Resource estimate of 9.00 million tonnes at 1.86% TREO. For the current resource estimate, the estimation methodology and grades within the block model are the same as the January 14, 2010 resource estimate. What has changed is the cut-off value used to report these resources and the re-classification of some of the previous Inferred Resources to Indicated Resources.
It is now recognised that a considerable portion of the total revenue from the Nechalacho deposit will be generated from zirconium and niobium sales. Metallurgical recovery data is now available for these (and other) elements and Scott Wilson RPA has re-stated the January, 14, 2010 resource estimate using a monetary cut-off value rather than an oxide (TREO) cut-off value. To do this, Scott Wilson RPA created an economic model using metal prices, the effects of payable percentages, flotation and hydrometallurgical recoveries, and any payable NSR Royalties. The net revenue generated by this model is termed the Net Metal Return ("NMR"). When the NMR model is applied to the 1.6% TREO cut-off grade for the Basal Zone used in the previous technical study (Wardrop, March 2009) the equivalent NMR value is approximately CND$500/tonnes. PFS operating cost estimates average CND$260/tonnes, and this has been applied as a break-even cut-off value for the resource estimate.
The general resource estimation parameters employed are summarized as follows:
- REE, Zr, Nb and Ta values are composited to two metre core lengths within discrete mineralized zones. Evaluation of raw assay grade values indicates that high grade values did not need capping.
- Metal assay composites and density measurements were temporarily flattened to the lower contact of the Basal Zone to facilitate the estimation procedure.
- Estimation of metal grades and density values within the two zones (Basal and Upper) in a flattened Gemcom(R) Surpac(R) Block Model (10m x 10m x 5m blocks with sub-blocking to 5m x 5m x 2.5m) using the Inverse Distance Squared method. A minimum of four composites and maximum of 15 composites were used to estimate the block values.
- Calculation of a NMR value for each block using metal prices and metallurgical recovery factors.
- Application of a cut-off grade, derived from the estimated operating cost, applied to the NMR of each block.
- Wire-framing of semi-contiguous blocks within the Basal and Upper Zones used to estimate separate tonnages and grades for the two zones.
The significant expansion of the Indicated Resources in the Basal Zone was one of the main contributing factors to the delay in announcing the results of the PFS. This was because the additional resources had a significant beneficial effect on the mine plan, and consequently on the financial model and the overall economics of the project.
Qualified Person
Christopher Moreton, PhD, P.Geo. (Ontario and New Brunswick), Senior Consulting Geologist at Scott Wilson RPA, is the Qualified Person as defined by National Instrument 43-101 for the purposes of this resource estimation and has verified that the technical information regarding the resources in this news release accurately reflects the technical information in the Prefeasibility Study. Drilling operations were performed under the supervision of J.C. Pedersen, P.Geo. Bruce Hudgins, P.Geo., maintains the geological database and monitors QA/QC on the laboratory analyses. and is also responsible for creating the initial wire-frames for the Nechalacho deposit, correcting any errors in the database and interpolating the values into the block model. The Company's Vice-President, Exploration, William Mercer, Ph.D., P.Geo. (Ont) and P.Geol (NWT) provided overall direction on the project.
(1) Total Rare Earth Oxides (TREO) refers to the elements lanthanum to lutetium, plus yttrium, expressed as oxides. See Avalon's website for conversion factors from elements to oxides. Heavy Rare Earth Oxides (HREO) refers to the elements europium to lutetium, plus yttrium, expressed as oxides as a percentage of the TREO. Light rare earths (LREO) refers to the elements lanthanum to samarium, expressed as oxides. HREO/TREO refers to the proportion of heavy rare earth oxides as a percentage of the total rare earth oxide content of the rock.
